Poultry Processing Wastewater Treatment Plant
* Effluent water can be discharged to inland water or it can be used as irrigation water.
* Initial investment cost and annual operational cost are very low.
* The capacity can be increased without major changes.
* Wastewater treatment plant system withstands to seasonal load variations
* System does not permit odours, flies and microbes. It does not disturb residents.
* Wastewater treatment plant can be easily transported from one place to another.
* Outer side can be painted as desired so that it gains an aesthetic view.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Product Description
* Effluent water can be discharged to inland water or it can be used as irrigation water.
* Initial investment cost and annual operational cost are very low.
* The capacity can be increased without major changes.
* Wastewater treatment plant system withstands to seasonal load variations
* System does not permit odours, flies and microbes. It does not disturb residents.
* Wastewater treatment plant can be easily transported from one place to another.
* Outer side can be painted as desired so that it gains an aesthetic view.
* Control room is separate. System operates without noise.
* It can easily start -up.
* All submerged parts are well protected from rust.
Technical Specifications
| NO. | Equipment | Specifications | Unit | BC-MP-1 | BC-MP-2 | BC-MP-4 |
1 | Flow | / | m3/d | 25 | 50 | 100 |
2 | Tank Size | Length | m | 6 | 12 | 12 |
Width | m | 2.4 | 2.4 | 3 | ||
Height | m | 2.4 | 2.4 | 3 | ||
3 | Bio Media | Proprietary | m3 | 3.3 | 6.6 | 13.2 |
4 | Settling Media | Tube-dek | m2 | 0.64 | 1 | 1.44 |
5 | Rotary Blower | Capacity | m3/h | 66 | 114 | 200 |
Pressure | m | 3 | 3 | 3.5 | ||
Motor HP | kw | 1.5 | 2.2 | 5.5 | ||
6 | Transfer Pump | Submersible | m3/h | 1 | 2 | 4 |
Head | m | 6 | 6 | 6 | ||
Motor HP | kw | 0.37 | 0.37 | 0.55 | ||
7 | Tertiary Disk Filters | Drive Motor | kw | 0.37 | 0.37 | 0.37 |
Pump Moter | kw | 0.37 | 0.37 | 0.37 | ||
8 | PAC | Drive Motor | kw | 0.37 | 0.37 | 0.37 |
Pump Moter | kw | 0.25 | 0.25 | 0.25 | ||
9 | PAM | Drive Motor | kw | 0.37 | 0.37 | 0.37 |
Pump Moter | kw | 0.25 | 0.25 | 0.25 | ||
10 | Shipping WT. | / | kg | 5500 | 10500 | 12500 |
11 | Operating WT. | / | kg | 8500 | 17200 | 21000 |
12 | Installed Power | / | / | 3.85 | 4.55 | 8.03 |
