304 Stainless Steel Wedge Wire Screen Pipe
BioCell 304 stainless steel wedge wire screen pipe is made of stainless steel wedge wire and support wire welded on the automatic welding machine. The stainless steel wedge wire screen has high strength and excellent corrosion resistance. Our wire wrapped screen adopts the unique trapezoidal wire design, which makes the V-shaped opening between the screen pipe crevice and ensures the smoothness of water resource filtration.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Product Description
BioCell 304 stainless steel wedge wire screen pipe is made of stainless steel wedge wire and support wire welded on the automatic welding machine. The stainless steel wedge wire screen has high strength and excellent corrosion resistance. Our wire wrapped screen adopts the unique trapezoidal wire design, which makes the V-shaped opening between the screen pipe crevice and ensures the smoothness of water resource filtration. The wedge wire specification and pipe end connection can also be customized as customers' requirements.
When vertical-mounted flat-panel sieves are used, an air-sparge system should be mounted along the bottom edge of the panels to periodically pulse the sieves and prevent any accumulation of waste.
|
|
| Horizontal Wedge Wire Screen Pipe Installation | Vertical Wedge Wire Screen Pipe Installation |
MBBR Screen Technical Specifications
No. | Model | Diameter (mm) | Length (mm) | Aperture Size (mm) | Wedge wire diameter (mm) | Connection Mode | Material |
1 | HS-150 | DN150 | 200~4000 | 5~12 | 2~3 | Flange | SS304/316/316L |
2 | HS-200 | DN200 | 200~4000 | 5~12 | 2~3 | Flange | SS304/316/316L |
3 | HS-250 | DN250 | 200~4000 | 5~12 | 2~3 | Flange | SS304/316/316L |
4 | HS-300 | DN300 | 200~4000 | 5~12 | 2~3 | Flange | SS304/316/316L |
5 | HS-350 | DN350 | 200~4000 | 5~12 | 2~3 | Flange | SS304/316/316L |
6 | HS-400 | DN400 | 200~4000 | 5~12 | 2~3 | Flange | SS304/316/316L |
7 | HS-450 | DN450 | 200~4000 | 5~12 | 2~3 | Flange | SS304/316/316L |
8 | HS-500 | DN500 | 200~4000 | 5~12 | 2~3 | Flange | SS304/316/316L |
9 | HS-550 | DN550 | 200~4000 | 5~12 | 2~3 | Flange | SS304/316/316L |
10 | HS-600 | DN600 | 200~4000 | 5~12 | 2~3 | Flange | SS304/316/316L |
